HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor,2+2 dual ban

Forsiden Huawei Networking - Fast Track HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor,2+2 dual ban
HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor, 2+2 dual ban (02354MXJ)
HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor, 2+2 dual ban (02354MXJ)
HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor, 2+2 dual ban (02354MXJ)
HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor, 2+2 dual ban (02354MXJ)

HUAWEI AirEngine5761-12 - AirEngine5761-12(11ax indoor,2+2 dual ban

Varenr.:
02354MXJ

For mere information om produkter eller konfigurationer af Huawei Networking, kontakt Tobias Gottschalk, +45 27 13 35 08, tobias.gottschalk@pedab.com eller Hawre Stark, +46 8 587 237 35, hawre.stark@pedab.se. Leveringstid 2 uger.
Beskrivelse

Huawei AirEngine 5761-12. Maksimal dataoverførselshastighed: 1000 Mbit/s, Netværksstandarder: IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, Antal brugere: 256 bruger(e). Sikkerhedsalgoritmer: WAPI, WEP, WPA2-PSK, WPA3-SAE. IPv4 & IPv6 funktioner: IPv4/IPv6 access-control list (ACL). Placering: Loft, Væg, Produktfarve: Hvid, Kabellåseslids type: Kensington. Antenne type: Intern, Niveau for antennestyrke (maks.): 4 dBi

Basic Information
Part Number
02354MXJ
Model
AirEngine 5761-12
Description
AirEngine5761-12(11ax indoor,2+2 dual bands,smart antenna,USB,IoT Slot,BLE)
First supported version
V200R021C10
Technical Specifications
Installation Type
Wall,Ceiling,T-Rail
Diameter [mm]
220 mm
Height [mm]
51 mm
Weight without packaging
1.09 kg (2.40 lb)
Weight with packaging
1.55 kg (3.42 lb)
Maximum number of physical ports on the entire device
GE (RJ45) x 2, 10M/100M/1000M auto-sensing
Maximum power consumption [W]
12.63 (excluding USB)
Maximum heat dissipation [BTU/h]
43.1
Power supply mode
DC adapter,PoE
Input voltage range [V]
DC: 12 V ± 10%
PoE: 802.3at/af
Rated input voltage [V]
12 V
802.3at power supply description
No function is limited.
DC power supply description
No function is limited.
802.3bt power supply description
No function is limited.
802.3af power supply description
Wi-Fi: 2.4 GHz (2x2) + 5 GHz (2x2). The maximum combined power is adjusted to 22 dBm (2.4 GHz) and 22 dBm (5 GHz).
Wired network port: The GE/PoE_IN port is available, but the GE port is unavailable.
Other ports: The USB port is unavailable.
Maximum transmit power [dbm]
2.4G:
20 dBm/chain
23 dBm (combined power)
5G:
20 dBm/chain
23 dBm (combined power)
BLE: < 10 dBm
Radio number
2
MIMO spatial streams
Radio 0 (2.4 GHz): 2x2
Radio 1 (5 GHz): 2x2
Radio interface
Built-in smart antennas
Operating frequency band
2.4GHz,5GHz
Wi-Fi standard
2.4G: 802.11b/g/n/ax
5G: 802.11a/n/ac/ac Wave 2/ax
Antenna gain
2.4G:
4 dBi/chain (peak value)
2 dBi (combined gain)
5G:
5 dBi/chain (peak value)
3 dBi (combined gain)
BLE: 4 dBi
Storage
NAND Flash 512 MB
Storage temperature
–40°C to +70°C (–40°F to +158°F)
Long-term operating temperature
–10°C to +50°C (14°F to 122°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.)
Long-term operating relative humidity [RH]
5% RH to 95% RH
Long-term operating altitude
–60 m to +5000 m (–196.85 ft to +16404.20 ft)
MTBF [year]
147
MTTR [h]
0.5
USB
USB 2.0
Console port
BLE console
Atmospheric pressure
53kPa - 106kPa ETSI 300 019-2-3
Service port surge protection [kV]
PoE port:
Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B
Common mode (8 wires to ground): 6 kV (1.2/50 us, 42 ohms), criterion B
Ground
floating ground
BLE
BLE5.2
3G/LTE filte (ACC)
Supported
